Helix devices have been proven to detect the sterilisation failures earlier, occurring due to non-condensable gases , bad steam conditions & time & temperature issues and as such enhances the quality control of the related department.
Ayka offers Batch monitoring by helix devices in various types of sterilisation methods like steam, EO and plasma. No need to wait for the BI result* and the load can immediately be released based upon the interpretation of the helix test.(* only non-implantable loads)
Chemical Indicators are considered as Class B Medical Device Under Medical Device Rules, 2017 vide G.S.R. 78 (E) by Govt. of India
1. Confirms to ISO 11140 -1 class 2
2. Clear and uniform colour change to black
3. Easy to interpret
4. Easy to document
5. Non-toxic/ Heavy metal free
| Specification | Detail |
|---|---|
| Cat No | PCDE1510060P |
| Units per pack (includes helix device, cotton bag, manual & colour reference) | 500 units |
| Overall Length | 70MM |
| Overall Width | 0.5MM |
| Back Adhesive | Yes |
| Product Type | Chemical Indicator |
| Product Type Free Format | Indicator Strip |
| Product Use | Load Monitoring |
| Sterilization Method | Ethylene Oxide |
| Colour Change | Yellow to Dark Brown/Black |
| Total Units per Case | 2000 |
| Specification | Detail |
|---|---|
| Cat No | PCDP1510060P |
| Units per pack (includes helix device, cotton bag, manual & colour reference) | 100 units |
| Overall Length | 70MM |
| Overall Width | 0.5MM |
| Back Adhesive | Yes |
| Product Type | Chemical Indicator |
| Product Type Free Format | Indicator Strip |
| Product Use | Load Monitoring |
| Sterilization Method | Plasma |
| Colour Change | Pink to Dark Brown/Black |
| Total Units per Case | 2000 |
| Specification | Detail |
|---|---|
| Cat No | PCDS1510060P |
| Units per pack (includes helix device, cotton bag, manual & colour reference) | 500 units |
| Overall Length | 70 MM |
| Overall Width | 0.5MM |
| Back Adhesive | Yes |
| Product Type | Chemical Indicator |
| Product Type Free Format | Indicator Strip |
| Product Use | Load Monitoring |
| Sterilization Method | Steam |
| Colour Change | Pink to Dark Brown/Black |
| Total Units per Case | 2000 |
